Databases and Developers

SELECT * FROM exciting_knowledge;

First off

Ask questions

at any time!

Who am I?

Kyle Tolle

kyletolle.com | @kyletolle

Software Engineer on Sabbatical

Not a database expert

but I want to

share

some of what

I’ve learned

Slides for this talk

Presentation:

https://kyletolle.github.io/dbs_and_devs_talk

Code:

https://github.com/kyletolle/dbs_and_devs_talk

Past Jobs

• tools supporting satellite simulation
• ICBM command and control system
• geospatial data collection
• mobile wallet applications

Overview

• Background
• ORMs
• DB Theory
• Important Concepts

Let’s start at

The Very Beginning

Humans are

knowledge-hunters

&

data-gatherers

We like to

• Collect data
• Store it
• Process it

Software crunches

data

Data needs

a home

a.k.a.

A Data Store

Data’s earliest home

The Flat File

cat students.csv

Id, Name, Grade
1,  Ted,  B
2,  Stan, A-
3,  Fred, C++
4,  Ned,  5%

Easy peasy

Some things don’t need to be complicated

Flat Files

can be used for

Data Interchange

Common flat file types

• CSV
• HTML
• XML
• JSON
• ini
• conf

Then, things grow

Complicated

Want to

• know more
• ask questions
• give access

Use the data for

• Web application
• Report generation
• Analysis performation

Fortunately for us,

some smart folks

invented the

database

Popular DBs according to Devs

https://insights.stackoverflow.com/survey/2017#technology-databases

Many common DBs use the

Relational Model

*

*: By User:AutumnSnow - Own work, CC BY-SA 3.0, Link

In other words, we have a

Table

with

Rows & Columns

SQL is a DSL

for managing data in a

Relational DB

Remember our student data?

Id, Name, Grade
1,  Ted,  B
2,  Stan, A-
3,  Fred, C++
4,  Ned,  5%

Put a database on it!

students

The table has a schema.

Each row is a record.

Each column is an attribute.

Let’s drop into

Postgres

Set up Postgres

brew install postgres
brew services start postgresql
createdb dbs_and_devs_talk
psql dbs_and_devs_talk

Create a Table

CREATE TABLE students(
  id SERIAL PRIMARY KEY,
  name TEXT NOT NULL,
  grade TEXT NOT NULL
);

Insert Data

INSERT INTO students (name, grade) values ('Ted', 'B');
INSERT INTO students (name, grade) values ('Stan', 'A-');
INSERT INTO students (name, grade) values ('Fred', 'C++');
INSERT INTO students (name, grade) values ('Ned', '5%');

View Data

SELECT * FROM students;

 id | name | grade
====+======+=======
  1 | Ted  | B
  2 | Stan | A-
  3 | Fred | C++
  4 | Ned  | 5%
(4 rows)

Create a Relationship

CREATE TABLE backpacks(
  id SERIAL PRIMARY KEY,
  color TEXT NOT NULL,
  student_id INT references students(id)
);

Insert Data

INSERT INTO backpacks (color, student_id) values('blue', 1);
INSERT INTO backpacks (color, student_id) values('red', 2);
INSERT INTO backpacks (color, student_id) values('grey', 3);
INSERT INTO backpacks (color, student_id) values('green', 4);
INSERT INTO backpacks (color, student_id) values('clear', 1);

View Data

SELECT * FROM backpacks;

 id | color | student_id
====+=======+============
  1 | blue  |          1
  2 | red   |          2
  3 | grey  |          3
  4 | green |          4
  5 | clear |          1
(5 rows)

Backback colors for a Student

SELECT color FROM backpacks WHERE student_id = 1;

 color
=======
 blue
 clear
(2 rows)

Backpacks for all students

SELECT s.name, b.color FROM students as s
  JOIN backpacks as b ON s.id = b.student_id
  ORDER BY s.name;

 name | color
======+=======
 Fred | grey
 Ned  | green
 Stan | red
 Ted  | blue
 Ted  | clear
(5 rows)

Quit Postgres

\q

Do stuff

the hard way

for a while

Allows you to understand

• the benefits of your tools
• the limits of your tools
• how to work around those limits

Plus, learn to

channel your anger

Useful Tools

• pgAdmin 4
• Postico
• ORMs

ORM

Object-Relational Mapping

Maps

database records

to

object instances

Ruby on Rails

follows the

Active Record pattern

Install Ruby

brew install rbenv
rbenv install 2.4.2
rbenv global 2.4.2

Ensure SQLite3 is installed

sqlite3 --version

Install Rails

gem install rails
rails --version

We expect to see Rails 5.1.4

Create Rails app

rails new blog
cd blog

Create Posts

rails generate scaffold Post title:string body:text

class CreatePosts < ActiveRecord::Migration[5.1]
  def change
    create_table :posts do |t|
      t.string :title
      t.text :body

      t.timestamps
    end
  end
end

Run db migration

rails db:migrate

Enter Ruby console

rails console

ActiveRecord is a DSL

We can modify SQL data with it

Create a new post

Post.create title: 'First!', body: 'Viral to the max.'

The console shows us

SQL queries

for various

ActiveRecord methods

Output for create

(0.1ms)  begin transaction
SQL (0.4ms)  INSERT INTO "posts"
  ("title", "body", "created_at", "updated_at")
  VALUES (?, ?, ?, ?)
  [
    ["title", "First!"],
    ["body", "Viral to the max."],
    ["created_at", "2017-11-29 01:37:50.231847"],
    ["updated_at", "2017-11-29 01:37:50.231847"]
  ]
(0.7ms)  commit transaction
=> #<Post id: 1, title: "First!",
     body: "Viral to the max.",
     created_at: "2017-11-29 01:37:50",
     updated_at: "2017-11-29 01:37:50">

Let’s break it down

• Transactions
• Queries
• Duration
• Conventions

Transactions

(0.1ms)  begin transaction
...
(0.7ms)  commit transaction

Multiple queries either

all happen

or

none happen

An error in a query causes a

Rollback

Provides protection from

Errors

causing

Inconsistent Data

Important when

modifying many records

in

one logical change

Queries

SQL (0.4ms)  INSERT INTO "posts"
  ("title", "body", "created_at", "updated_at")
  VALUES (?, ?, ?, ?)
  [
    ["title", "First!"],
    ["body", "Viral to the max."],
    ["created_at", "2017-11-29 01:37:50.231847"],
    ["updated_at", "2017-11-29 01:37:50.231847"]
  ]

Dynamically generated

ActiveRecord analyzes the table and

generates the correct query

Duration

SQL (0.4ms)  INSERT INTO "posts" ...

ActiveRecord measures

how long

each query takes to run

Can help

profile queries

and find slow ones

Conventions

Naming

Table name (posts) is pluralized

Class name (Post) is singular

Handles

complex cases

like

people & Person

Timestamps

Notice the

updated_at & created_at

columns?

ActiveRecord automatically tracks

creation & modification

times of each record

Other Examples

Viewing

post = Post.last

SELECT  "posts".* FROM "posts"
  ORDER BY "posts"."id" DESC LIMIT ?  [["LIMIT", 1]]
=> #<Post id: 1,
          title: "First!",
          body: "Viral to the max.",
          created_at: "2017-11-29 01:37:50",
          updated_at: "2017-11-29 01:37:50">

Using

post.title

=> "First!"

post.updated_at

=> Wed, 29 Nov 2017 02:31:07 UTC +00:00

Counting

Post.count

SELECT COUNT(*) FROM "posts"
=> 1

Destroying

Post.destroy_all

SELECT "posts".* FROM "posts"
DELETE FROM "posts" WHERE "posts"."id" = ?  [["id", 1]]

Just a sample

This is not an exhaustive list

Exit Rails Console

exit

Add a Column to Post

rails g migration AddCurrentSongToPosts current_song:string

class AddCurrentSongToPosts < ActiveRecord::Migration[5.1]
  def change
    add_column :posts, :current_song, :string
  end
end

Migrations support

rolling back schema

rails db:rollback

Create a Relationship

rails g model like post:references

class CreateLikes < ActiveRecord::Migration[5.1]
  def change
    create_table :likes do |t|
      t.references :post, foreign_key: true

      t.timestamps
    end
  end
end

• Adds indexes for post_id

Complex Relationship

An author can publish many posts, and

a post can have many authors

Complex Relationship, cont.

rails g model author name:string email:string

class CreateAuthors < ActiveRecord::Migration[5.1]
  def change
    create_table :authors do |t|
      t.string :name
      t.string :email

      t.timestamps
    end
  end
end

Complex Relationship, cont.

rails g migration CreateJoinTableAuthorsPosts author post

class CreateJoinTableAuthorsPosts < ActiveRecord::Migration[5.1]
  def change
    create_join_table :authors, :posts do |t|
      # t.index [:author_id, :post_id]
      # t.index [:post_id, :author_id]
    end
  end
end

Even Complexerer

Sometimes the join tables are more complex

• Give the concept a name, like Publications
• Treat it like a model itself
• Consider needing additional data, like a
  • primary_author boolean attribute
  • royalty_earned money attribute
• Use Timestamps to know when changes happen

Quick detour into

Database Theory

ACID

A single DB can provide

• Atomicity
• Consistency
• Isolation
• Durability

CAP Theorem

In the event of a network failure,

a distributed DB must choose between

• consistency
• availability

BASE

Some distributed DBs prioritize availability.

Eventually, all the data will be consistent.

• Basically Available
• Soft state
• Eventual consistency

Other Topics

ORMs

support multiple databases through

DB Adapters

ORMS

generate queries on the fly, so

are slower than hard-coded queries

ORMs

inflate objects with

data from the DB, which

isn’t ideal for bulk work

Alternate SQL Library

like sequel for Ruby

might be more performant

N+1 Query Explosions

ORMS may lazily fetch data, resulting in

1,000+1 queries for

1,000 posts by 1 author

Primary Key

Key (like id) that uniquely identifies this record

No two records have the same primary key

Foreign Key

Key (like post_id) that uniquely identifies

some other row in a different table or in this table

Why reference a row in the same table?

To allow parent-child relationships

Indexes

Can speed up lookups, but

require extra space on disk and

slow down writes

Sanitization

Never trust user input

SQL injection can cause your DB to be hacked

Some ORMs may sanitize some data by default

Responsibility falls on you

to ensure data is sanitized

before entering your system

Permissions

Some users might only need read-only access

Review DB permissions to reduce risk of accidental

deletion or modification

Normalization

Removing duplication across tables

Normal Forms

• 1NF
• 2NF
• 3NF
  • “Nothing but the key”

Constraints

• primary key
• foreign key
• not null
• unique

Migrations

Changing the database schema as your needs change

Migrations, cont.

• Migrating the database by hand is tricky
• Need to be consistent
• Need to do it across many machines (many developers)
• Need to do it differently in different environments
  • PRD has multiple DBs whereas DEV has one local DB

Migrations, cont.

• Take databases offline
  • Can make changes that would break your application
• Keep databases online
  • Have to make sure old version of app works with new DB schema
  • Might have to make multiple deployments

Migrations, cont.

To keep the db online and rename a column:

• First deploy
  • Duplicate column old_name to one called new_name
  • Add code that updates new_name as well as old_name

Migrations, cont.

• Second deploy
  • Change all code references from old_name to new_name
  • Remove now-unused column old_name

Data integrity

Application-level integrity vs Database-level integrity

• Database can enforce referential integrity
  • Post exists when creating a like
• Application can enforce higher-level things
  • Only a person with specific permissions can modify this post

Locks

Adding a non-null column to a large table

can lock the table

and prevent reads or writes

Locks, cont.

To prevent a long table lock:

• Add a column that allows null values
  • Table is only locked for a short time
• Update each row to have a default value
  • This will lock each row for a short time
• Update the column to not allow null values
  • Since each column already has a value, the lock is released quickly

Scaling

• Vertical
  • Faster CPUs
  • More Memory
  • More Disk Space
  • Caching
  • Partitioning data across tables

Scaling, cont.

• Horizontal
  • Load balancing
  • Create a pool of nodes
  • Add more nodes to the pool
  • Sharding data across nodes

Scaling, cont.

• Tools to manage bigness
  • gh-ost for migrations
  • Hadoop

Fault tolerance

If one node goes down,

another can still serve requests

Recovery

Make regular backups of databases

Recovery, cont.

Have a restore process

Try out the restore process

to make sure it works!

NoSQL DBs

• MongoDB is a document-based store
• Redis is a key-value store
• Cassandra is a column-based store
• Neo4j is a graph-based store

Other topics to consider

• Data Types
• Views
• Triggers
• Full text search
• Security

Other topics to consider, cont.

• Stored Procedures
• Reports/Analytics
• Spatial extensions
• Self-hosted vs Cloud-hosted

Links

• Flat files
• Relational model
• Relational database
• SQL
• Tables
• Fields
• Active Record pattern
• Views
• Transactions
• Commits

Links, cont.

• Rollback
• Distributed data store
• Normalization overview
• Rails ActiveRecord Basics
• Use the Index, Luke
• Python ORMs
• Khan Academy SQL Basics
• 101 things I wish I knew…

Drop Postgres table

dropdb dbs_and_devs_talk

Thanks!
